Specifications – 5114A_B
| Parameter | Specification |
|---|---|
| Product Type | Universal Programmable Transmitter |
| Channels | 2-channel (indicated by 'B' suffix) |
| Input Types | RTD, TC, mV, linear resistance, mA, and V |
| Galvanic Isolation | 3-port 3.75 kVAC |
| Supply Voltage | 21.6...253 VAC / 19.2...300 VDC |
| Dimensions (HxWxD) | 109 x 23.5 x 130 mm |
| Operating Temperature | -20°C to +60°C |
| Mounting Type | DIN rail (DIN 46277) |
